Solid State SR-F 408

• Country
• Japan

• Manufacturer / Brand
• Standard Radio Corp. (SR), Tokyo

• Year
• 1969–1972 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122977

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 6

• Semiconductors
• 2SA102 2SA101 2SA101 2SB175 2SB172 2SB172

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Dry Batteries / AA: 2 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Power out
• 0.1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Solid State SR-F 408 - Standard Radio Corp. SR, Tokyo

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 109 x 73 x 31 mm / 4.3 x 2.9 x 1.2 inch

• Notes

• Standard SR-F408.
  Coverage: 540 - 1600 KHz, earphone jack.

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Literature/Schematics (1)
• Radio es Televizio Vevö keszülekek 1972-75

• Literature/Schematics (4)
• Rences Tamás, Rádiókapcsolások II. Budapest 1975.

• Author
• Model page created by Sándor Selyem-Tóth. See "Data change" for further contributors.

• Other Models

• Here you find 256 models, 243 with images and 110 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Standard Radio Corp. (SR), Tokyo
