Tiny Pal SR-G900L

Tiny Pal SR-G900L; Standard Radio Corp. (ID = 2556264) Radio

Tiny Pal SR-G900L; Standard Radio Corp. (ID = 2556265) Radio

Tiny Pal SR-G900L; Standard Radio Corp. (ID = 2556266) Radio

Tiny Pal SR-G900L; Standard Radio Corp. (ID = 2556267) Radio
Tiny Pal SR-G900L; Standard Radio Corp. (ID = 1620538) Radio Tiny Pal SR-G900L; Standard Radio Corp. (ID = 1620539) Radio
Tiny Pal SR-G900L; Standard Radio Corp. (ID = 1620541) Radio Tiny Pal SR-G900L; Standard Radio Corp. (ID = 1620542) Radio
Use red slider bar for more.
Tiny Pal SR-G900L; Standard Radio Corp. (ID = 1620538) Radio
Standard Radio Corp.: Tiny Pal SR-G900L [Radio] ID = 1620538 900x522
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tiny Pal SR-G900L, Standard Radio Corp. (SR), Tokyo

Country:  Japan
Manufacturer / Brand:  Standard Radio Corp. (SR), Tokyo
Year: 1962 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7:
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / UM3: 2 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 6 cm = 2.4 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Tiny Pal SR-G900L - Standard Radio Corp. SR, Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 115 x 65 x 35 mm / 4.5 x 2.6 x 1.4 inch
Notes

Mit Ledertasche und Ohrhörer.
Aufschraubbare Antenne.

Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)

Model page created by Gerhard Härtl. See "Data change" for further contributors.



All listed radios etc. from Standard Radio Corp. (SR), Tokyo
Here you find 239 models, 223 with images and 84 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
