• Country
• Japan

• Manufacturer / Brand
• Standard Radio Corp. (SR), Tokyo

• Year
• 1994 ?

• Category
• Commercial Transmitter & Receiver (TRX not Amateur)

• Radiomuseum.org ID
• 293338

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Transceiver

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Powered by external power supply or a main unit. / 13,2 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2 W (max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: VHF Repeater - Repetidor RP-80V F1, F3, F5 - Standard Radio Corp. SR, Tokyo

• Shape
• Rack

• Dimensions (WHD)
• 482 x 132 x 400 mm / 19 x 5.2 x 15.7 inch

• Notes

• Standard Radio RP-80V VHF Repeater. 100 channels selectable. 50W RF output power.
  25 kHz channel spacing. Includes CTCSS.

  Variants:

  F1 from 136 to 150 MHz
  F3 from 146 to 162 MHz
  F5 from 160 to 174 MHz

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Author
• Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
