• Country
• Japan

• Manufacturer / Brand
• Star Co. Ltd.; Tokyo

• Year
• 1967

• Category
• Amateur Transmitter (only)

• Radiomuseum.org ID
• 94733

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 13

• Valves / Tubes
• 6EA8 6EA8 6AQ8 6AQ8 6DK6 6EA8 6DK6 6AW8 12BY7 6146 6146 6EA8 6EA8

• Wave bands
• Short Wave (SW only)

• Power type and voltage
• Alternating Current supply (AC) / 115 / 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: ST-700 - Star Co. Ltd.; Tokyo

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 385 x 185 x 370 mm / 15.2 x 7.3 x 14.6 inch

• Notes
• 80 to 10 meters HAM bands, AM/CW/SSB. HF output 100 watts PEP. There was model numbers with suffix characters A and E, differences unknown. Matches receiver SR-700.

• Price in first year of sale
• 1,498.00 DM

• Mentioned in
• R. Birchel, KW-Amateurfunkgeräte in Röhrentechnik

• Literature/Schematics (1)
• Katalog H.Bauer 1968

• Literature/Schematics (2)
• Funk-Technik (FT) (2/1967, S. 56, 58, 60 / Beschreibung, Teilschema)

• Author
• Model page created by a member from D. See "Data change" for further contributors.
