For model ST105U, Stella Radio & Television Company Ltd.; London:
My Stella ST105U mains AC/DC 5 valve MW/LW transportable radio in its compact brown bakelite cabinet. c. 1954

Country:  Great Britain (UK)
Manufacturer / Brand:  Stella Radio & Television Company Ltd.; London
Year: 1953 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UF41 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: ST105U - Stella Radio & Television
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 12.5 x 9.25 x 6.5 inch / 318 x 235 x 165 mm
Notes

The UK Philips 151U is very similar but without handle  and using a Ferrite Rod aerial instead  of Loop Frame aerial. Stella was simply a "Brand label" for UK Philips at this time.

Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data -- Schematic
Literature/Schematics (1) Paul Stenning CD Vol 4

Model page created by Keith Staines. See "Data change" for further contributors.
