• Country
• Great Britain (UK)

• Manufacturer / Brand
• Stella Radio & Television Company Ltd.; London

• Year
• 1953 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 127880

• Number of Tubes
• 5

• Valves / Tubes
• UCH42 UF41 UBC41 UL41 UY41

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110; 200-220; 220-245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: ST107U - Stella Radio & Television

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 320 x 200 x 140 mm / 12.6 x 7.9 x 5.5 inch

• Notes
• Similar chassis to Philips 131U/210U. Eingebaute Rahmen- und Flächenantenne.

• Net weight (2.2 lb = 1 kg)
• 2.9 kg / 6 lb 6.2 oz (6.388 lb)

• Source of data
• -- Schematic

• Author
• Model page created by Keith Staines. See "Data change" for further contributors.

• Other Models

• Here you find 92 models, 53 with images and 49 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Stella Radio & Television Company Ltd.; London
