• Country
• Germany

• Manufacturer / Brand
• Stern-Radio Berlin, VEB, RFT, (Kombinat); - vorm. Phonetika Radio (Ostd.) - vorm. Loewe Opta AG

• Year
• 1967–1971

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 108842

• • alternative name: Phonetika Radio Berlin, VEB; Berlin, (Ostd.)

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• GF132 GF181 GF130 GC101 GC116 GC117 GC121 GA113 GA101 OA780

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Tuned circuits
• 5 AM circuit(s)     9 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Dry Batteries / 2x4,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 0.45 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Stern Favorit R120 UKW - Stern-Radio Berlin, VEB, RFT,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 255 x 162 x 72 mm / 10 x 6.4 x 2.8 inch

• Notes

• Gerät aus der Baureihe R120, Modell mit Kurzwelle; vergleiche Stern Piccolo, Stern Hobby. Zwei Wellenbereiche, keine Klangregelung, Skala für UKW in Frequenz und Kanal geeicht, Gegentaktendstufe mit Trafos. Das Gerät hat einen Holzkorpus mit Plastikrückwand.

  Halbleitertypen nur einmal aufgeführt

• Net weight (2.2 lb = 1 kg)
• 2.2 kg / 4 lb 13.5 oz (4.846 lb)

• Price in first year of sale
• 405.00 DM

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
