Concerton L33

Concerton L33; Stern & Stern (ID = 1805917) Radio Concerton L33; Stern & Stern (ID = 1805918) Radio
Concerton L33; Stern & Stern (ID = 151415) Radio Concerton L33; Stern & Stern (ID = 151416) Radio
Concerton L33; Stern & Stern (ID = 151417) Radio Concerton L33; Stern & Stern (ID = 240782) Radio
Concerton L33; Stern & Stern (ID = 1805919) Radio Concerton L33; Stern & Stern (ID = 1805920) Radio
Concerton L33; Stern & Stern (ID = 1805921) Radio Concerton L33; Stern & Stern (ID = 1805922) Radio
Use red slider bar for more.
Concerton L33; Stern & Stern (ID = 1805917) Radio
Stern & Stern: Concerton L33 [Radio] ID = 1805917 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Concerton L33, Stern & Stern (Concerton / Conserton), S&S; Stockholm:
Stern & Stern, Stockholm, Modell Concerton L33 - 1

Country:  Sweden
Manufacturer / Brand:  Stern & Stern (Concerton / Conserton), S&S; Stockholm
Year: 1930 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: RE074 RE074 RE114
Main principle TRF with regeneration; Neutrodyne
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Direct Current supply (DC) / 220 Volt
Loudspeaker -Loudspeaker incorporated, but system not known. / Ø 28 cm = 11 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Concerton L33 - Stern & Stern Concerton /
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 360 x 360 x 300 mm / 14.2 x 14.2 x 11.8 inch
Notes According to the add from April 1930 Stern & Stern has been an exporter - at least to Belgium. The add shows something like a model number 30. The Concerton has incorporated a loudspeaker and an entry for a record player.
Net weight (2.2 lb = 1 kg) 6 kg / 13 lb 3.5 oz (13.216 lb)
Price in first year of sale 225.00 SEK
Collectors' prices
Mentioned in A Blast from the Past, p. 82.

Model page created by Gabor Baronfeind † ?.4.16. See "Data change" for further contributors.



All listed radios etc. from Stern & Stern (Concerton / Conserton), S&S; Stockholm
Here you find 370 models, 177 with images and 57 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
