Radiola 342V

Radiola 342V; SRA Svenska (ID = 218063) Radio

Radiola 342V; SRA Svenska (ID = 218064) Radio

Radiola 342V; SRA Svenska (ID = 218065) Radio
Radiola 342V; SRA Svenska (ID = 422133) Radio Radiola 342V; SRA Svenska (ID = 422218) Radio
Radiola 342V; SRA Svenska (ID = 422219) Radio Radiola 342V; SRA Svenska (ID = 422217) Radio
Use red slider bar for more.
Radiola 342V; SRA Svenska (ID = 422133) Radio
SRA Svenska: Radiola 342V [Radio] ID = 422133 442x440
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola 342V, SRA Svenska Radioaktiebolaget; Stockholm

Country:  Sweden
Manufacturer / Brand:  SRA Svenska Radioaktiebolaget; Stockholm
Brand

Radiola
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: MPT4 MS4B U10
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Radiola 342V - SRA Svenska Radioaktiebolaget;
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 315 x 310 x 190 mm / 12.4 x 12.2 x 7.5 inch
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Price in first year of sale 150.00 SKR
Source of data - - Data from my own collection

Model page created by Sven Lindstrom. See "Data change" for further contributors.
