For model Sonneberg Batteriesuper 85/57BII Holz-Gehäuse, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG:
Top gold trim is missing

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1957/1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: DK96 DF96 DF96 DAF96 DL96
Main principle Super-Heterodyne (Super in general); ZF/IF 473 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 1,5 & 90 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.12 W (unknown quality)
from Radiomuseum.org Model: Sonneberg Batteriesuper 85/57BII [Holz-Gehäuse] - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 486 x 322 x 185 mm / 19.1 x 12.7 x 7.3 inch
Notes Auch als Version im Plastik-Gehäuse (Bakelit) gebaut: 85/57BII.
Price in first year of sale 322.00 Mark
Literature/Schematics (1) Service-DVD Funkverlag Hein

Model page created by Kevin Gregson. See "Data change" for further contributors.
