Carino 530

Carino 530; Stern-Radio (ID = 553233) Radio

Carino 530; Stern-Radio (ID = 553234) Radio

Carino 530; Stern-Radio (ID = 553235) Radio

Carino 530; Stern-Radio (ID = 553236) Radio

Carino 530; Stern-Radio (ID = 553237) Radio

Carino 530; Stern-Radio (ID = 553238) Radio

Carino 530; Stern-Radio (ID = 553239) Radio

Carino 530; Stern-Radio (ID = 2584452) Radio

Carino 530; Stern-Radio (ID = 2584453) Radio

Carino 530; Stern-Radio (ID = 2584454) Radio
Carino 530; Stern-Radio (ID = 1929671) Radio Carino 530; Stern-Radio (ID = 1929672) Radio
Carino 530; Stern-Radio (ID = 1929673) Radio Carino 530; Stern-Radio (ID = 2509979) Radio
Carino 530; Stern-Radio (ID = 2509980) Radio Carino 530; Stern-Radio (ID = 50401) Radio
Carino 530; Stern-Radio (ID = 505173) Radio Carino 530; Stern-Radio (ID = 50402) Radio
Carino 530; Stern-Radio (ID = 50403) Radio Carino 530; Stern-Radio (ID = 50404) Radio
Use red slider bar for more.
Carino 530; Stern-Radio (ID = 1929671) Radio
Stern-Radio: Carino 530 [Radio] ID = 1929671 1400x918
Select picture or schematic to display from thumbnails on the right and click for download.
For model Carino 530, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1966 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH81 UBF89 UCL82 UY82
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 1.6 W (unknown quality)
from Radiomuseum.org Model: Carino 530 - Stern-Radio Sonneberg, VEB,
Material Plastics (no bakelite or catalin)
Dimensions (WHD) 360 x 170 x 168 mm / 14.2 x 6.7 x 6.6 inch
Notes Modernes Kunststoffgehäuse, 4 Tasten. Kurzwellenbereich von 5,95 bis 6,2 MHz (49-m-Band), induktive Abstimmung, Klangtaste.
Die Chassis wurden bei John-Radio KG Apolda gefertigt.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 180.00 DM
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967 (Service- DVD vom Funkverlag B. Hein.)


All listed radios etc. from Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Here you find 385 models, 310 with images and 280 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
