• Year
  • 1980
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 77901

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 7 AM circuit(s)     16 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: K10 SC1700 - Stern-Radio Sonneberg, VEB,
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 462 x 1045 x 405 mm / 18.2 x 41.1 x 15.9 inch
  • Notes
  • HiFi-Turm besteht aus den Gerätekomponenten HiFi-Tuner 922, HiFi-Verstärker 926, HiFi-Schallplattenabspielgerät Granat 216-1, HiFi-Kassettenbandgerät SK 910.
  • Net weight (2.2 lb = 1 kg)
  • 48 kg / 105 lb 11.6 oz (105.727 lb)
  • Price in first year of sale
  • 7,200.00 DM
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Author
  • Model page created by Bernd Pötzsch. See "Data change" for further contributors.
