Stern-Radio: Rostock 4930 D [Radio] ID = 1609315 933x524
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1963 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 4: ECH81 EBF89 PCL82 EZ80 |
|---|
| Main principle | Super-Heterodyne (Super in general); ZF/IF 455 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) |
| Wave bands | Broadcast, Long Wave and 2 x Short Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 150; 180; 200; 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch |
| Power out | 1.6 W (unknown quality) |
| from Radiomuseum.org | Model: Rostock 4930 D - Stern-Radio Sonneberg, VEB, |
| Material | Wooden case |
| Shape | Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only). |
| Dimensions (WHD) | 350 x 160 x 150 mm / 13.8 x 6.3 x 5.9 inch |
| Notes | Rostock 4930D, ein Exportgerät mit 2 x Kurzwelle, Mittel und Lang im polierten edelholzfurnierten Holzgehäuse. Das Chassis entspricht dem Rostock 493B im Plastgehäuse. |
| Net weight (2.2 lb = 1 kg) | 5 kg / 11 lb 0.2 oz (11.013 lb) |
| Mentioned in | Die Geschichte der Rundfunkindustrie der DDR Band 1 1945 - 1967 |
| Literature/Schematics (1) | Service- DVD vom Funkverlag B. Hein |
