ST3000HIFI; Stern-Radio (ID = 583946) Radio
Stern-Radio: ST3000HIFI [Radio] ID = 583946 932x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model ST3000HIFI OIRT, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1982–1985 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 13:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: ST3000HIFI [OIRT] - Stern-Radio Sonneberg, VEB,
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 300 x 60 x 260 mm / 11.8 x 2.4 x 10.2 inch
Notes Exportversion mit OIRT Band 65,5 ....73 MHz.3-fache kapazitive FM-Abstimmung, Pilottonfilter für UKW, 5-KHz-Filter für Kurzwelle, AM-Abstimmung 2-fach kapazitiv, LED Anzeige Feldstärke und Stereo.
Net weight (2.2 lb = 1 kg) 3.3 kg / 7 lb 4.3 oz (7.269 lb)
Source of data -- Original-techn. papers.

Model page created by Wolfgang Lill. See "Data change" for further contributors.
