SV3900 HiFi; Stern-Radio (ID = 516459) Ampl/Mixer
Stern-Radio: SV3900 HiFi [Ampl/Mixer] ID = 516459 900x296
Select picture or schematic to display from thumbnails on the right and click for download.
For model SV3900 HiFi, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG:
Serien Nr.:

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1982 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 13:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 26 W (undistorted)
from Radiomuseum.org Model: SV3900 HiFi - Stern-Radio Sonneberg, VEB,
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 390 x 60 x 260 mm / 15.4 x 2.4 x 10.2 inch
Notes Der Verstärker SV3900 entspricht in seiner elektrischen Konzeption dem SV3000. Er ist eine Komponente der Anlage S3900, bestehend aus dem Tuner ST3900, dem Kassettendeck SK3900, dem Equalizer SQ3900 und dem Plattenspieler SP3900. Die Ausgangsleistung beträgt 2x 13 Watt Sinus.
Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Price in first year of sale 740.00 M
Source of data -- Original prospect or advert
Mentioned in Service-DVD Funkverlag B. Hein

Model page created by Wolfgang Lill. See "Data change" for further contributors.
