Transmira 6190

Transmira 6190; Stern-Radio (ID = 1329320) Radio

Transmira 6190; Stern-Radio (ID = 1329321) Radio
Transmira 6190; Stern-Radio (ID = 1083312) Radio Transmira 6190; Stern-Radio (ID = 403027) Radio
Transmira 6190; Stern-Radio (ID = 403028) Radio Transmira 6190; Stern-Radio (ID = 1083313) Radio
Transmira 6190; Stern-Radio (ID = 1083314) Radio
Use red slider bar for more.
Transmira 6190; Stern-Radio (ID = 1083312) Radio
Stern-Radio: Transmira 6190 [Radio] ID = 1083312 933x410
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transmira 6190, Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG:
Sammlung Albert Weiss

Country:  Germany
Manufacturer / Brand:  Stern-Radio Sonneberg, VEB, RFT; SONRA; -vorm.: EAK (Ostd.) - ex. AEG
Year: 1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: GF132 GF181 GF130 GF130 GF130 GC117 GC116 GC116 GD160 GD160 OA721 GA101 GA101 GA109 GA109
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Transmira 6190 - Stern-Radio Sonneberg, VEB,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 450 x 145 x 145 mm / 17.7 x 5.7 x 5.7 inch
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Source of data - - Data from my own collection
Mentioned in -- Schematic
Literature/Schematics (1) Radio es Televizio Vevö keszülekek 1967-69

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
