Transmiranda 6200
Stern-Radio: Transmiranda 6200 [Radio] ID = 830402 933x376
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1968 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | 10: GF132 GF181 GF130 GF130 GF130 GC117 GC116 GC116 GD160 GD160 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 455/10700 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 10 FM circuit(s) |
| Wave bands | Broadcast, Short Wave plus FM or UHF. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 160-240 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | 1.5 W (unknown quality) |
| from Radiomuseum.org | Model: Transmiranda 6200 - Stern-Radio Sonneberg, VEB, |
| Material | Wooden case |
| Shape | Tablemodel with Push Buttons. |
| Dimensions (WHD) | 500 x 140 x 156 mm / 19.7 x 5.5 x 6.1 inch |
| Net weight (2.2 lb = 1 kg) | 4 kg / 8 lb 13 oz (8.811 lb) |
| External source of data | Serviceheft Sternradio Sonneberg |
| Source of data | Radiokatalog Band 2, Ernst Erb |
Model page created by Michael Seiffert. See "Data change" for further contributors.
