• Year
  • 1936
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 61981
    • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 10
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz; 2 AF stage(s)
  • Tuned circuits
  • 9 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and 2 x Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 @ 25/60 Hz Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 145-LB Ch= P-26289 - Stromberg-Carlson Co. ;
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Notes
  • The Stromberg-Carlson model 145-LB is a 10 tube, AC operated LW/BC/Police/SW band receiver.

    Band Frequencies:
    Longwave Band ("Band X"): 145-370kHz
    Broadcast Band ("Band A"): 530-1700kHz
    Police Band ("Band B"): 1700-5600MHz
    SW Band ("Band C"): 5.6-18.0MHz

    Uses 25-60Hz AC power source. Uses all metal tubes. Bi-resonator input circuit for BC band. Has Eye Tube. Also has push-pull output stage and 2 IF gain stages.
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 7 = 1936 and before
  • Mentioned in
  • Rider's 7-23 to 7-26
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Stromberg-Carlson Datasheet P-26992 Form 2124 Issue 1)
