Te-Lek-Tor-Et | ||||
|---|---|---|---|---|---|
| Year: 1951 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 10: 6BA6 6BA6 12AT7 6BE6 6BA6 6BA6 6AL5 6AU6 6V6GT 5Y3GT |
| Main principle | Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s) |
|---|---|
| Tuned circuits | 7 AM circuit(s) 9 FM circuit(s) |
| Wave bands | Broadcast (BC) and FM or UHF. |
| Details | Record Player (perh.Changer) |
| Power type and voltage | Alternating Current supply (AC) / 117 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | 3.8 W (unknown quality) |
| from Radiomuseum.org | Model: 1507PLA Ch=112113 - Stromberg-Carlson Co. ; |
| External source of data | Ernst Erb |
| Circuit diagram reference | Rider's Perpetual, Volume 22, covering 1951 |
| Literature/Schematics (1) | Beitman Radio Diagrams, Vol. 11, 1951 |
