• Year
  • 1936
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 61998
    • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 14
  • Main principle
  • Superhet with RF-stage; ZF/IF 465 kHz; 3 AF stage(s)
  • Tuned circuits
  • 9 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and more than two Short Wave bands.
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • from Radiomuseum.org
  • Model: 160-LB - Stromberg-Carlson Co. ;
  • Notes
  • LW (145-370 kHz), BC (530-1700 kHz), TROP (1700-5600 kHz), SW1 (5.6-18.0 MHz) and SW2 (18.0-60.0 MHz) bands. Tuning eye, push-pull audio amplifier. For 25 or 60 Hz AC.
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 8 = 1937 and before
  • Mentioned in
  • Rider's 8-10 to 8-14, 9-5, 9-6, Changes 11-3
