• Year
  • 1939
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 62087
    • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 335 Series - Stromberg-Carlson Co. ;
  • Shape
  • Console with Push Buttons.
  • Notes
  • The Stromberg-Carlson model 335 Series are AC operated 7 tube BC and SW band receivers. The BC Band frequency range is 530-1700kHz with six station preset buttons. The SW Band frequency range is 5.9-18.0MHz. Has Tuning eye.

    Models ending with a "B" operate from 25-60 cycle AC power, while models that do not end with a "B" operate from 50-60 cycle AC power.
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 10 = 1939 and before
  • Mentioned in
  • Rider's 10-16 to 10-18, 10-30
  • Literature/Schematics (2)
  • - - Manufacturers Literature (Stromberg Carlson Datasheet P-29099 Issue 1)
