360-MB Ch= P29069
Stromberg-Carlson Co. ; Rochester (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Stromberg-Carlson Co. ; Rochester (NY)
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 62129
-
- Brand: Te-Lek-Tor-Et
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 9 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 25-60 cycles, 105-125 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 1.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 360-MB Ch= P29069 - Stromberg-Carlson Co. ;
- Shape
- Console with Push Buttons.
- Notes
- The Stromberg-Carlson model 630-M is an 25-60 cycle AC operated 12 tube BC/Police/SW band receiver. Has eight auto-tune BC band station buttons.
Band Frequencies:
Broadcast Band ("Band A"): 530-1700kHz
Police Band ("Band B"): 1700-5600MHz
SW Band ("Band C"): 5.6-18.0MHz
Has Tuning eye, AFC and push-pull audio output amplifier. Also has optional remote control that drives a tuning motor and volume control motor located inside the chassis.
