For model AF-501B, Stromberg-Carlson Co. ; Rochester (NY):
Picture from service manual.

Country:  United States of America (USA)
Manufacturer / Brand:  Stromberg-Carlson Co. ; Rochester (NY)
Brand

Te-Lek-Tor-Et
Year: 1958 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: 6AV6 12AX7 6V6GT 6V6GT 6X5GT
Main principle Audio-Amplification
Wave bands - without
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: AF-501B - Stromberg-Carlson Co. ;
Material Wooden case
Shape Console with any shape - in general
Notes

Stromberg-Carlson model AF-501B is an AC operated phono amplifier with 4 speed automatic record changer.

Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 385 Folder 11 dated 1-58)

Model page created by Dirk Taekels. See "Data change" for further contributors.
