For model AF-681K, Stromberg-Carlson Co. ; Rochester (NY):
Sams Photofact Folders

Country:  United States of America (USA)
Manufacturer / Brand:  Stromberg-Carlson Co. ; Rochester (NY)
Brand

Te-Lek-Tor-Et
Year: 1959 Category: Sound/Video Recorder and/or Player
Valves / Tubes 6: ECC83 ECC83 6AV6 6L6GB 6L6GB 5U4GB
Main principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 110 - 120 Volt
Loudspeaker 5 Loudspeakers
Power out
from Radiomuseum.org Model: AF-681K - Stromberg-Carlson Co. ;
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes The Stromberg Carlson Model AF-681K is an AC operated 6 Tube Phono Amplifier with 4 Speed Automatic Record Changer.
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 11-59, Set 464, Folder 18)

Model page created by Egon Penker. See "Data change" for further contributors.
