• Country
• United States of America (USA)

• Manufacturer / Brand
• Stromberg-Carlson Co. ; Rochester (NY)

• Year
• 1957 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 311985

• • Brand: Te-Lek-Tor-Et

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 17

• Valves / Tubes
• 6BQ7A 6AU6 6BQ7A 6BA6 6BE6 6BA6 6BA6 6AU6 6AL5 6AL5 12AD7 12AX7 12AX7 6L6GT 6L6G EM85 5U4GB

• Main principle
• Superhet with RF-stage; ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: SR-406 - Stromberg-Carlson Co. ;

• Shape
• Tablemodel, with any shape - general.

• Notes

• Stromberg-Carlson model SR-406 is an AC operated FM-AM receiver.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 364 Folder 14 dated 7-57)

• Author
• Model page created by Dirk Taekels. See "Data change" for further contributors.
