For model Caterina, Stuzzi Ges. mbH; Wien

Country:  Austria
Manufacturer / Brand:  Stuzzi Ges. mbH; Wien
alternative name

RKF
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: SFT319 SFT319 SFT319 SFT352 SFT323 SFT323
Main principle Superheterodyne (common)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2 × 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Caterina - Stuzzi Ges. mbH; Wien
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 220 x 140 x 60 mm / 8.7 x 5.5 x 2.4 inch
Notes

Technisch identisch zu Arel PP8 und Clarville PP8.

Net weight (2.2 lb = 1 kg) 0.9 kg / 1 lb 15.7 oz (1.982 lb)
Price in first year of sale 830.00 ATS
External source of data Gerhard Heigl
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Museums Bote, Österr. (Heft 45 / Mai-Juni 2013, S. 16ff Gerätevorstellung)

Model page created by Gerhard Heigl. See "Data change" for further contributors.



All listed radios etc. from Stuzzi Ges. mbH; Wien
Here you find 98 models, 85 with images and 53 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
