For model RKF Ton-Boy, Stuzzi Ges. mbH; Wien:
RKF Ton-Boy

Country:  Austria
Manufacturer / Brand:  Stuzzi Ges. mbH; Wien
alternative name

RKF
Year: 1952 Category: Sound/Video Recorder and/or Player
Valves / Tubes 3: 6AU6 6AT6 6AQ5
Main principle Audio-Amplification
Details Tape Recorder
Power type and voltage Powered by external power supply or a main unit. / 240-/6,3~ Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: RKF Ton-Boy - Stuzzi Ges. mbH; Wien
Material Metal case
Shape Tablemodel, with any shape - general.
Notes Aufsatzgerät für Plattenspieler, keine Montage notwendig. Spieldauer 20 Minuten. Frequenzumfang ca. 40 bis 7000 Hz. Die Spannungen können entweder aus dem Radiogerät entnommen werden oder von einem getrennten Netzgerät (Röhre: 6X4) zum Preis von 410.- ATS.
Price in first year of sale 1'340.00 ATS
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.



All listed radios etc. from Stuzzi Ges. mbH; Wien
Here you find 98 models, 85 with images and 53 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
