For model 623T, Superla - Cresa; Modena

Country:  Italy
Manufacturer / Brand:  Superla - Cresa; Modena
alternative name

Cresa Radio; Modena
Year: 1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: SFT358 SFT357 SFT316 SFT316 SFT316 SFT337 SFT353 SFT325 SFT325
schematic requested
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 0.8 W (unknown quality)
from Radiomuseum.org Model: 623T - Superla - Cresa; Modena
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 380 x 160 x 140 mm / 15 x 6.3 x 5.5 inch
Notes

Sette diodi. Mobile in legno con frontale e retro in plastica.

See also identical model Intel Baden-Baden.

FM-Chassis= CS100, RF-Chassis= CS200.

Source of data -- Schematic

Model page created by Fabio Masetti. See "Data change" for further contributors.
