TRCS 133M

Supersonic (Chassay Bros), Bulawayo, SR

Data
Forum
Pictures
Collections

  • Year
  • 1966 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 243632

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • FM Broadcast Band Only
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 200; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: TRCS 133M - Supersonic Chassay Bros,
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 604 x 295 x 95 mm / 23.8 x 11.6 x 3.7 inch
  • Notes

  • Supersonic Radio / Cassette Tape Recorder

    • 50 Cycles, max 54 Watts
    • Tape speed 4,76 cm/sec, Tape counter
    • FM Aerial 300 Ohm input
    • Gram Input (from unit TP-133 AS) / Dynamics cartridge
    • AM Tuner input from unit TU-133M
    • AFC
    • Loudspeaker 8 Ohms, Left/Right
    • FM Insto-matic Tuning, VU Left/Right
    • Mic input, Record level switch Manual/Auto.
  • Net weight (2.2 lb = 1 kg)
  • 9 kg / 19 lb 13.2 oz (19.824 lb)
  • Author
  • Model page created by J. Virgilio Santos. See "Data change" for further contributors.
