Röhrenvoltmeter - Вольтомметр VK 7-9 - ВК 7-9; Tallinn Punane RET (ID = 422049) Equipment
Tallinn Punane RET: Röhrenvoltmeter - Вольтомметр VK 7-9 - ВК 7-9 [Equipment] ID = 422049 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Röhrenvoltmeter - Вольтомметр VK 7-9 - ВК 7-9, Tallinn Punane RET Radio Works:
Gerät WK7-9 (BK7-9)

Country:  Estonia (Eesti, Tallinn)
Manufacturer / Brand:  Tallinn Punane RET Radio Works
Year: 1965 Category: Service- or Lab Equipment
Valves / Tubes 4: 6Н2П-ЕВ 6Н16Б-В 6Д13Д 6Д13Д СГ202Б СГ202Б
Semiconductors (the count is only for transistors) 3: П4_Transistor П15 П202
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 115; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Röhrenvoltmeter - Вольтомметр VK 7-9 - ВК 7-9 - Tallinn Punane RET Radio Works
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 290 x 220 x 140 mm / 11.4 x 8.7 x 5.5 inch
Notes Röhrenvoltmeter: 0,3 V - 1 kV~, 0,3 V - 500 V=, 100 Ω - 100 MΩ.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Source of data -- Schematic

Model page created by Helmut Matysik. See "Data change" for further contributors.
