Baandopptaker TB6

Baandopptaker TB6; Tandberg Radio; Oslo (ID = 753050) R-Player

Baandopptaker TB6; Tandberg Radio; Oslo (ID = 753051) R-Player

Baandopptaker TB6; Tandberg Radio; Oslo (ID = 753052) R-Player

Baandopptaker TB6; Tandberg Radio; Oslo (ID = 753053) R-Player
Baandopptaker TB6; Tandberg Radio; Oslo (ID = 57016) R-Player Baandopptaker TB6; Tandberg Radio; Oslo (ID = 282837) R-Player
Baandopptaker TB6; Tandberg Radio; Oslo (ID = 282838) R-Player Baandopptaker TB6; Tandberg Radio; Oslo (ID = 282839) R-Player
Use red slider bar for more.
Baandopptaker TB6; Tandberg Radio; Oslo (ID = 57016) R-Player
Tandberg Radio; Oslo: Baandopptaker TB6 [R-Player] ID = 57016 581x512
Select picture or schematic to display from thumbnails on the right and click for download.
For model Baandopptaker TB6, Tandberg Radio; Oslo:
From Tandberg Radio\'s Service Manual by Ernst Rykkje

Country:  Norway
Manufacturer / Brand:  Tandberg Radio; Oslo
Year: 1960–1966 Category: Sound/Video Recorder and/or Player
Valves / Tubes 10: ECC82 ECC82 ECC83 ECC83 EAM86 EAM86 ECC83 ECC83 ECC83 ECC83
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Baandopptaker TB6 - Tandberg Radio; Oslo
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 405 x 305 x 150 mm / 15.9 x 12 x 5.9 inch
Net weight (2.2 lb = 1 kg) 11.3 kg / 24 lb 14.2 oz (24.89 lb)

Model page created by Ernst Rykkje. See "Data change" for further contributors.



All listed radios etc. from Tandberg Radio; Oslo
Here you find 201 models, 171 with images and 106 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Tandberg Radio; Oslo: Baandopptaker TB6
Threads: 1 | Posts: 1
Hits: 3391     Replies: 0
tandberg: TB6; Baandopptaker
Bo Samuelsson
01.Jan.07
  1

Model 6 is one of Tandbergs top models, it was manufactured 1960 - 1966. It has high performance stereo record and playback amplifiers with cathode follower output for use with a separate output amplifier and speaker system.The tape recorder can record and play in full stereo with four track technique, which means two tracks on one half of the tape and two tracks on the other half after turning the tape. It has three speeds, 7 1/2 "/sec, 3 3/4 "/sec och 1 7/8 "/sek.

As can be seen in the picture of the tape transport there are three heads, erase, record and playback head.  Because there are separate record and playback amplifiers it is possible to listen to the recording after the record head to check the quality and also to make some trick recordings, for example sound-on-sound and echo.

Technical data:
Bandwidth
7 1/2 "/s    30 - 20000 Hz +-3dB
3 3/4 "/s    30 - 14000 Hz
1 7/8 "/s    50 -   7000 Hz
Distorsion  3% max (at 400 Hz with full volume indicated on the magic eye)
Wow better than 0,15%, 0,2% or 0,3% at the different tape speeds
Noise level better than 55 dB at full volume
Erase and premagnetizing frequency 78 kHz

The overview picture shows the recorder ready for stereo playback (playback 1 and 2 pressed).
The next picture shows the chassis with the mains transformer upper left, the synchronous motor in the center with the oscillator board beneath it. The record and playback amplifiers are hidden in the screening shield to the right. The last picture shows the tape transport with the three heads.
