Sølvsuper - Soelvsuper 4 ; Tandberg Radio; Oslo (ID = 54879) Radio
Tandberg Radio; Oslo: Sølvsuper - Soelvsuper 4 [Radio] ID = 54879 738x388
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sølvsuper - Soelvsuper 4, Tandberg Radio; Oslo

Country:  Norway
Manufacturer / Brand:  Tandberg Radio; Oslo
Year: 1946/1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH35 EBF32 EF39 EL33 6U5 or 6G5 5Y3G or U50
Main principle Superheterodyne (common); ZF/IF 465 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 130; 150; 200; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out
from Radiomuseum.org Model: Sølvsuper - Soelvsuper 4 - Tandberg Radio; Oslo
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 630 x 270 x 260 mm / 24.8 x 10.6 x 10.2 inch
Notes

Wavebands: LW 140 - 370 kHz, MW 500 - 1600 kHz, SW 5.8 - 18 MHz.

Net weight (2.2 lb = 1 kg) 13.2 kg / 29 lb 1.2 oz (29.075 lb)
Price in first year of sale 458.00 NOK
Mentioned in -- Original-techn. papers.

Model page created by Ernst Rykkje. See "Data change" for further contributors.
