TR-2055

TR-2055; Tandberg Radio; Oslo (ID = 1888837) Radio
TR-2055; Tandberg Radio; Oslo (ID = 177619) Radio TR-2055; Tandberg Radio; Oslo (ID = 177620) Radio
TR-2055; Tandberg Radio; Oslo (ID = 1277902) Radio TR-2055; Tandberg Radio; Oslo (ID = 1779105) Radio
TR-2055; Tandberg Radio; Oslo (ID = 1888838) Radio TR-2055; Tandberg Radio; Oslo (ID = 1888839) Radio
TR-2055; Tandberg Radio; Oslo (ID = 1888841) Radio TR-2055; Tandberg Radio; Oslo (ID = 1888842) Radio
Use red slider bar for more.
TR-2055; Tandberg Radio; Oslo (ID = 177619) Radio
Tandberg Radio; Oslo: TR-2055 [Radio] ID = 177619 900x420
Select picture or schematic to display from thumbnails on the right and click for download.
For model TR-2055, Tandberg Radio; Oslo:
By courtesy of Lauritz.com

Country:  Norway
Manufacturer / Brand:  Tandberg Radio; Oslo
Year: 1976/1977 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 120; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 160 W (unknown quality)
from Radiomuseum.org Model: TR-2055 - Tandberg Radio; Oslo
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 510 x 153 x 353 mm / 20.1 x 6 x 13.9 inch
Notes Amplifier: 2 x 80 W sinus, 4 Ohm.
Aluminium Front mit Palisandergehäuse. FM-Teil gleich wie beim TR-2075MkII.
Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Price in first year of sale 5'000.00 NKr.
Source of data -- Schematic
Mentioned in Funkschau (23/1976, S. 979 / HiFi 76 in Düsseldorf)

Model page created by Ernst Rykkje. See "Data change" for further contributors.
