Super 46 (R46)
Técalémit Radio; Paris
- Country
- France
- Manufacturer / Brand
- Técalémit Radio; Paris
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 214766
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 475 kHz; Reflex
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 150; 225 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 19.5 cm = 7.7 inch
- Power out
- 2.6 W (unknown quality)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Super 46 - Técalémit Radio; Paris
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 425 x 310 x 200 mm / 16.7 x 12.2 x 7.9 inch
- Notes
-
Montage reflex, antifading. Réglage de sensibilité. Prise pick-up et HP supplémentaire.
Coffret en bakélite.
Même présentation que le Super 54 mais avec 2 gammes d'ondes et 4 lampes.
- Price in first year of sale
- 1,195.00 FRF
- Mentioned in
- -- Original prospect or advert (Gamme 1936)
- Author
- Model page created by Armand Verboven. See "Data change" for further contributors.
- Other Models
-
Here you find 23 models, 20 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Técalémit Radio; Paris
Collections
The model Super is part of the collections of the following members.
