Picoskop EO1/7 - TPW

Picoskop EO1/7 - TPW; Technisch- (ID = 846951) Equipment

Picoskop EO1/7 - TPW; Technisch- (ID = 846952) Equipment

Picoskop EO1/7 - TPW; Technisch- (ID = 846953) Equipment
Picoskop EO1/7 - TPW; Technisch- (ID = 2079773) Equipment Picoskop EO1/7 - TPW; Technisch- (ID = 2079776) Equipment
Picoskop EO1/7 - TPW; Technisch- (ID = 357840) Equipment Picoskop EO1/7 - TPW; Technisch- (ID = 529273) Equipment
Picoskop EO1/7 - TPW; Technisch- (ID = 1009768) Equipment Picoskop EO1/7 - TPW; Technisch- (ID = 1009769) Equipment
Picoskop EO1/7 - TPW; Technisch- (ID = 1009770) Equipment Picoskop EO1/7 - TPW; Technisch- (ID = 1009771) Equipment
Picoskop EO1/7 - TPW; Technisch- (ID = 1021035) Equipment Picoskop EO1/7 - TPW; Technisch- (ID = 1034939) Equipment
Use red slider bar for more.
Picoskop EO1/7 - TPW; Technisch- (ID = 2079773) Equipment
Technisch-: Picoskop EO1/7 - TPW [Equipment] ID = 2079773 1351x1891
Select picture or schematic to display from thumbnails on the right and click for download.
For model Picoskop EO1/7 - TPW, Technisch-Physikalische Werkstätten, (TPW), VEB; Thalheim (Ostd.)

Country:  Germany
Manufacturer / Brand:  Technisch-Physikalische Werkstätten, (TPW), VEB; Thalheim (Ostd.)
alternative name

TPW
Year: 1958 ? Category: Service- or Lab Equipment
Valves / Tubes 5: ECF82 ECF82 ECF82 ECF82 B7S1
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Picoskop EO1/7 - TPW - Technisch-Physikalische Werkst
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 125 x 185 x 205 mm / 4.9 x 7.3 x 8.1 inch
Notes Service-Kleinoszillograf 2,5 Hz bis 1 MHz. - Ab etwa 1963 hergestellt in PGH Radio-Fernsehen-Elektro, Marienberg (siehe "radioferns").
Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Price in first year of sale 611.00 DM
Source of data - - Manufacturers Literature
Mentioned in Anders; Schaltungssammlung der Meßgeräte; DDR 1979

Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
