Quartz Synthesizer FM/AM Stereo Tuner ST-C04

Technics (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1980–1982
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 154465

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 120; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Quartz Synthesizer FM/AM Stereo Tuner ST-C04 - Technics brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 297 x 49 x 232 mm / 11.7 x 1.9 x 9.1 inch
  • Notes

  • "Micro Series" Quartz Synthesizer FM/AM Stereo Tuner Model Technics ST-C04.
    Frequency Range:
    FM 87,9 - 107,9 MHz (0,2 MHz step)
    FM 87,50 - 108,00 MHz (0,05 MHz step)
    AM 530 -1620 kHz (10 kHz step)
    AM 522 - 1611 kHz (9 kHz step)
    6 FM / 6 AM Presets
    Auto Channel Search
    Digital Frequency Display
    Memory Protection with golden Capacitor (without Battery)
    Power Consumption 8 Watts.


  • Net weight (2.2 lb = 1 kg)
  • 1.816 kg / 4 lb 0 oz (4 lb)
  • Price in first year of sale
  • 250.00 $
  • Mentioned in
  • - - Manufacturers Literature (Service Manual)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
