Cassette Stereo Deck RS-271US

Technics (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1973
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 154984

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 120; 90-109; 110-125; 200-219; 220-250 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Cassette Stereo Deck RS-271US - Technics brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 15.625 x 5 x 10.875 inch / 397 x 127 x 276 mm
  • Notes

  • A stereo hi-fi cassette deck with Dolby B. With 2 heads, 1 motor, 3 digit tape counter, Normal/Cr02 tape selector, left and right VU level meters. Jacks for microphone, phono Line input, phono Line output, DIN tape input/output socket and a jack for headphones.

    Specification
    Motor: Electronic speed control motor
    Recording System : AC bias
    Erase System: AC erase
    Track System: 4-track, 2-channel stereo recording & playback
    Tape Speed: 1⅞ ips
    Wow and Flutter: Less than 0.15% (WRMS)
    Frequency Response: 20-13,000 Hz (with normal tape)
    20-14,000 Hz (with Cr02 tape)
    Signal to Noise Ratio: 45 dB (in normal operation)
    55 dB (in Dolby operation)
    Inputs :
      MIC
      LINE    		 -70 dB (0.3 mV)/600-20kΩ
    -30 dB (30 mV)/150kΩ
    Outputs :
      LINE
      HEADPHONE    		 -6 dB (500 mV) / load impedance 50K over
    8Ω
    Record/Playback 1-DIN connection

    Versions/Power Requirements
    120V AC 50/60Hz
    90-109, 110-125, 200-219, 220-250 volts AC 50/60 Hz with voltage selector

    Power Consumption: Approx. 15 W

    Same as the National Panasonic RS-271US Cassette Stereo Deck.

  • Net weight (2.2 lb = 1 kg)
  • 13 lb 4 oz (13.25 lb) / 6.016 kg
  • Price in first year of sale
  • 250.00 $
  • Literature/Schematics (1)
  • - - Manufacturers Literature (Service Manual Technics RS-271US)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
