Stereo Turntable SL-BD 22

Stereo Turntable SL-BD 22; Technics brand (ID = 626013) R-Player

Stereo Turntable SL-BD 22; Technics brand (ID = 626011) R-Player

Stereo Turntable SL-BD 22; Technics brand (ID = 626012) R-Player

Stereo Turntable SL-BD 22; Technics brand (ID = 626014) R-Player

Stereo Turntable SL-BD 22; Technics brand (ID = 626015) R-Player

Stereo Turntable SL-BD 22; Technics brand (ID = 626016) R-Player

Stereo Turntable SL-BD 22; Technics brand (ID = 626017) R-Player
Stereo Turntable SL-BD 22; Technics brand (ID = 2273561) R-Player Stereo Turntable SL-BD 22; Technics brand (ID = 2273560) R-Player
Stereo Turntable SL-BD 22; Technics brand (ID = 2273559) R-Player Stereo Turntable SL-BD 22; Technics brand (ID = 2273563) R-Player
Stereo Turntable SL-BD 22; Technics brand (ID = 2273562) R-Player Stereo Turntable SL-BD 22; Technics brand (ID = 1381958) R-Player
Stereo Turntable SL-BD 22; Technics brand (ID = 1381959) R-Player Stereo Turntable SL-BD 22; Technics brand (ID = 1381960) R-Player
Stereo Turntable SL-BD 22; Technics brand (ID = 1381961) R-Player Stereo Turntable SL-BD 22; Technics brand (ID = 285259) R-Player
Use red slider bar for more.
Stereo Turntable SL-BD 22; Technics brand (ID = 2273561) R-Player
Technics brand: Stereo Turntable SL-BD 22 [R-Player] ID = 2273561 1381x1162
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Turntable SL-BD 22, Technics (brand)

Country:  Japan
Manufacturer / Brand:  Technics (brand)
Year: 1988 ? Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Turntable SL-BD 22 - Technics brand
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 430 x 93 x 375 mm / 16.9 x 3.7 x 14.8 inch
Net weight (2.2 lb = 1 kg) 3.6 kg / 7 lb 14.9 oz (7.93 lb)
Price in first year of sale 329.00 DM
Source of data - - Manufacturers Literature

Model page created by Vitor Oliveira. See "Data change" for further contributors.



All listed radios etc. from Technics (brand)
Here you find 1020 models, 970 with images and 167 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Technics brand: Stereo Turntable SL-BD 22
Threads: 1 | Posts: 10
Hits: 6790     Replies: 9
Technics SL-BD22
Vitor Oliveira
06.Jan.07
  1

Hello dear all,

I have a audio-turntable Technics Model SL-BD22 and the drive belt is not in place, I make a search in the Rmorg and cannot find this model... anyone can help me please with some data and the schematic or the best way to put the drive belt in place?

Thanks in advance,

Vitor



Jeffrey Angus
06.Jan.07
  2 Vitor, could you take a picture of the turn table? Perhaps it would be evident if we could see it. Or perhaps someone else will recognize the style and think, "Hey, that looks like mine...." and look to see how their belt is attached.

Jeff
Ernst Erb
06.Jan.07
  3 Dear Vitor
You are very active in RMorg and have uploaded about 3000 pictures and 1223 schematics, congratulations.

You have entered also about 2000 new models and made 14470 changes to models. Therefore we will naturally try very much to help you - but please enter the model and load up the pictures to the model. Then you can ask me to move this to the model and I will remind our community with anotehr post to it. Thank you.
Wolfgang Bauer
06.Jan.07
  4

This is a brandnew model.
The belt will be mounted on the underside of the turntable to the driving pinion.

Regards WB.

Rolf Nickel
06.Jan.07
  5 Dear Vitor,

it seems to me that I use the same or a similar model since two years, see the attached picture.
If you need more information or more photos from inside, please tell me.



Best regards
Rolf
Vitor Oliveira
09.Jan.07
  6

Thank you all for try help me.

Dear Wolfgang, thank you for the explanation about the belt in your nice pic, anyway I try to put the belt in place like you show here and seems are bigger for the place! Any idea please?

Dear Rolf, yes please I'm greatful if you can send me a pic with the belt in place.

Dear Erb, I uploaded right now the model...

Thanks,

Vitor



Rolf Nickel
10.Jan.07
  7 Dear Vitor,

I think Wolfgang's picture shows exactly the run of the belt, sea also my detail-photo and the overview. The belt runs round the bottom of the turntable and the drive wheel only, there are no further "points of touch".






Might be that the belt you got does not fit, e. g. it is too long.

Best regards
Rolf
Maitiu Standun
10.Jan.07
  8 hi vitor , by any chance is the belt the one which was originally fitted  ? or is it a belt that u purchased ??? if its an old belt , it has almost certainly stre tched , if its a new one its the wrong one ,regards maitiu.
Vitor Oliveira
10.Jan.07
  9

Thank you all,

Yes, seems the original belt is now too long becouse it was just growing by age!!

It is normal? I think the solution for the problem is buy another belt for this model, any link please?

all the best,

Vitor

Wolfgang Bauer
11.Jan.07
  10

Hallo Mr. Oliveira,

your belt has the size:
186mm x 4mm x 0,6mm. (flat)
You can get it in every repair shop for Radios and TV.
They can order it for you.

Regards WB.


Technics brand: Stereo Turntable SL-BD 22
End of forum contributions about this model
