Stereo Cassette Deck RS-B58R

Technics (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1983/1984
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 155082

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Cassette Deck RS-B58R - Technics brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 98 x 273 mm / 16.9 x 3.9 x 10.7 inch
  • Notes

  • Frontloading Auto Reverse Stereo Cassette Deck with Dolby B + C, DBX Type II and Metal Tape Capability.
    3-Digit Mechanical Counter, Digital Peak-Reading Meters, Multi Color Peak-Reading Meters, Peak Hold.
    Microprocessor Logic Control System.

    Type: auto reverse, 2-head, single compact cassette deck
    Track System: 4-track, 2-channel stereo
    Tape Speed: 4.8 cm/s
    Heads: 1 x record/playback, 1 x erase
    Tape Type: type I, CrO2, Metal
    Noise Reduction: B, C, DBX
    Frequency Response: 20Hz to 20kHz  (Metal tape)
    Signal to Noise Ratio: 92dB  (DBX)
    Wow and Flutter: 0.05%
    Input: 60mV (line), 0.25mV (mic)
    Output: 0.4V (line)

  • Net weight (2.2 lb = 1 kg)
  • 5 kg / 11 lb 0.2 oz (11.013 lb)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
