Stereo Cassette Deck RS-B608R

Technics (brand)

Data
Forum
Pictures
Collections

  • Year
  • 1988–1990
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 155091

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player; Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Cassette Deck RS-B608R - Technics brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 115 x 287 mm / 16.9 x 4.5 x 11.3 inch
  • Notes

  • Frontloading 2-Head Class AA Stereo Cassette Deck with Dolby B + C, MPX Filter, DBX Type II, Dolby HX Pro and Metal Tape Capability.
    4-Digit Digital Counter, Digital Peak-Reading Meters, Multi Color Peak-Reading Meters, Record Indicator.
    Music Scan, Timer Recording/Playback.

    Type: auto reverse, 2-head, single compact cassette deck
    Track System: 4-track, 2-channel stereo
    Tape Speed: 4.76 cm/s
    Heads: 1 x record/playback, 1 x erase
    Motor: 1 x capstan, 1 x reel
    Tape Type: type I, CrO2 (type II), Metal (type IV)
    Noise Reduction: Dolby B, C, DBX, HX Pro
    Frequency Response: 20Hz to 19kHz  (Metal tape)
    Signal to Noise Ratio: 92dB  (DBX)
    Wow and Flutter: 0.08%
    Input: 60mV (line), 0.25mV (mic)
    Output: 0.4V (line)

  • Net weight (2.2 lb = 1 kg)
  • 4.3 kg / 9 lb 7.5 oz (9.471 lb)
  • Price in first year of sale
  • 470.00 $
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
