Stereo Cassette Deck RS-B705

Stereo Cassette Deck RS-B705; Technics brand (ID = 2108721) R-Player Stereo Cassette Deck RS-B705; Technics brand (ID = 2108718) R-Player
Stereo Cassette Deck RS-B705; Technics brand (ID = 2108719) R-Player Stereo Cassette Deck RS-B705; Technics brand (ID = 2108720) R-Player
Stereo Cassette Deck RS-B705; Technics brand (ID = 2108722) R-Player Stereo Cassette Deck RS-B705; Technics brand (ID = 2108723) R-Player
Stereo Cassette Deck RS-B705; Technics brand (ID = 2108724) R-Player Stereo Cassette Deck RS-B705; Technics brand (ID = 2108725) R-Player
Stereo Cassette Deck RS-B705; Technics brand (ID = 1306685) R-Player Stereo Cassette Deck RS-B705; Technics brand (ID = 1306686) R-Player
Use red slider bar for more.
Stereo Cassette Deck RS-B705; Technics brand (ID = 2108721) R-Player
Technics brand: Stereo Cassette Deck RS-B705 [R-Player] ID = 2108721 1400x594
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Cassette Deck RS-B705, Technics (brand)

Country:  Japan
Manufacturer / Brand:  Technics (brand)
Year: 1987–1989 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Cassette Deck RS-B705 - Technics brand
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 285 x 110 mm / 16.9 x 11.2 x 4.3 inch
Notes

Frontloading 3-Head Class AA Stereo Cassette Deck with Dolby B + C, Double Dolby NR Circuits and Metal Tape Capability.
Bias Fine Tune, Microprocessor Logic Control System.
4-Digit Digital Counter, Digital Peak-Reading Meters, Multi Color Peak-Reading Meters.
Music Scan, Timer Recording/Playback.
Bias Fine Tune.

Type: 3-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x combination record/playback, 1 x erase
Motor: 1 x capstan, 1 x reel
Tape Type: Type I (Fe2O3), Type II (CrO2), Type IV (Metal)
Noise Reduction: Dolby B, C, HX Pro
Frequency Response: 20Hz to 21kHz  (Metal tape)
Signal to Noise Ratio: 75dB  (Dolby C)
Wow and Flutter: 0.05% (WMRS)
Input: 60mV (line)
Output: 0.4V (line)

Net weight (2.2 lb = 1 kg) 4.4 kg / 9 lb 11.1 oz (9.692 lb)
Price in first year of sale 550.00 $

Model page created by Franz Scharner. See "Data change" for further contributors.
