Stereo Cassette Deck RS-M260

Stereo Cassette Deck RS-M260; Technics brand (ID = 1847519) R-Player
Stereo Cassette Deck RS-M260; Technics brand (ID = 2144341) R-Player Stereo Cassette Deck RS-M260; Technics brand (ID = 2144338) R-Player
Stereo Cassette Deck RS-M260; Technics brand (ID = 2144339) R-Player Stereo Cassette Deck RS-M260; Technics brand (ID = 2144340) R-Player
Stereo Cassette Deck RS-M260; Technics brand (ID = 2144342) R-Player Stereo Cassette Deck RS-M260; Technics brand (ID = 2144343) R-Player
Stereo Cassette Deck RS-M260; Technics brand (ID = 2144344) R-Player Stereo Cassette Deck RS-M260; Technics brand (ID = 2144345) R-Player
Stereo Cassette Deck RS-M260; Technics brand (ID = 659850) R-Player
Use red slider bar for more.
Stereo Cassette Deck RS-M260; Technics brand (ID = 2144341) R-Player
Technics brand: Stereo Cassette Deck RS-M260 [R-Player] ID = 2144341 1400x639
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo Cassette Deck RS-M260, Technics (brand)

Country:  Japan
Manufacturer / Brand:  Technics (brand)
Year: 1980/1981 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 110; 125; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Stereo Cassette Deck RS-M260 - Technics brand
Material Metal case
Shape Book-shelf unit.
Dimensions (WHD) 430 x 119 x 282 mm / 16.9 x 4.7 x 11.1 inch
Notes

Frontlaoding 3-Head Stereo Cassette Deck with Dolby B and Metal Tape Capability.

Type: 3-head, single compact cassette deck
Track System: 4-track, 2-channel stereo
Tape Speed: 4.8 cm/s
Heads: 1 x combination record/playback, 1 x erase
Motor: electrical governor DC
Tape Type: type I, FeCr, CrO2, Metal
Noise Reduction: B
Frequency Response: 20 Hz to 20 kHz  (Metal tape)
Signal to Noise Ratio: 67 dB  (dolby B)
Wow and Flutter: 0.05%
Input: 60 mV (line), 0.25 mV (mic)
Output: 0.7 V (line)

Net weight (2.2 lb = 1 kg) 5.3 kg / 11 lb 10.8 oz (11.674 lb)
Price in first year of sale 380.00 $
Documents about this model
  Service manual 1366 KB
