Stereo Integrated Amplifier SU-V650

Technics (brand)

  • Year
  • 1988
  • Category
  • Audio Amplifier or -mixer
  • Radiomuseum.org ID
  • 154724

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 180 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Stereo Integrated Amplifier SU-V650 - Technics brand
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 159 x 363 mm / 16.9 x 6.3 x 14.3 inch
  • Notes
  • Stereo Integrated Amplifier with 90 watts RMS per channel into 8 ohms.
    Class of Operation: AA.

    Power output: 90 watts per channel into 8Ω (stereo),
    Frequency response: 3Hz to 100kHz,
    Total harmonic distortion: 0.002%,
    Damping factor: 80,
    Input sensitivity: 0.17mV (MC), 2.5mV (MM), 150mV (line),
    Signal to noise ratio: 65dB (MC), 78dB (MM), 92dB (line),
    Channel separation: 50dB (line),
    Output: 150mV (line),
    Speaker load impedance: 4Ω to 16Ω

  • Net weight (2.2 lb = 1 kg)
  • 9.988 kg / 22 lb 0 oz (22 lb)
  • Price in first year of sale
  • 590.00 $
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
