Stereo Integrated DC Amplifier SU-V3
Technics (brand)
- Country
- Japan
- Manufacturer / Brand
- Technics (brand)
- Year
- 1981/1982
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 154544
Original prospekt.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 80 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Stereo Integrated DC Amplifier SU-V3 - Technics brand
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 430 x 97 x 310 mm / 16.9 x 3.8 x 12.2 inch
- Notes
-
Stereo Integrated DC Amplifier
Class of Operation: NEW A.Power output: 40 W per channel into 8 Ω (stereo)
Frequency response: 2 Hz to 100 kHz
Total harmonic distortion: 0.03 %
Damping factor: 40
Input sensitivity: 2.5 mV (MM), 150 mV (DIN), 150 mV (line)
Signal to noise ratio: 82 dB (MM), 100 dB (line)
Channel separation: 55 dB (line)
Output: 150 mV (line), 30 mV (DIN)
Speaker load impedance: 4 Ω to 16 Ω
- Net weight (2.2 lb = 1 kg)
- 8.172 kg / 18 lb 0 oz (18 lb)
- Price in first year of sale
- 280.00 $
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
