KML 50A

KML 50A; Tefag; Telephon (ID = 7137) Radio

KML 50A; Tefag; Telephon (ID = 1579614) Radio
KML 50A; Tefag; Telephon (ID = 2520834) Radio KML 50A; Tefag; Telephon (ID = 2520836) Radio
KML 50A; Tefag; Telephon (ID = 2520828) Radio KML 50A; Tefag; Telephon (ID = 2520837) Radio
KML 50A; Tefag; Telephon (ID = 2520831) Radio KML 50A; Tefag; Telephon (ID = 2520832) Radio
KML 50A; Tefag; Telephon (ID = 2520833) Radio KML 50A; Tefag; Telephon (ID = 2520835) Radio
KML 50A; Tefag; Telephon (ID = 2520830) Radio KML 50A; Tefag; Telephon (ID = 2520829) Radio
Use red slider bar for more.
KML 50A; Tefag; Telephon (ID = 2520834) Radio
Tefag; Telephon: KML 50A [Radio] ID = 2520834 1400x1095
Select picture or schematic to display from thumbnails on the right and click for download.
For model KML 50A, Tefag; Telephon Aktiengesellschaft vorm. J. Berliner

Country:  Germany
Manufacturer / Brand:  Tefag; Telephon Aktiengesellschaft vorm. J. Berliner
alternative name

Telephon-Fabrik, AG vorm. J. Berliner
Year: 1942–1944 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH11 UBF11 UCL11 UY11
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: KML 50A - Tefag; Telephon
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 289 x 180 x 153 mm / 11.4 x 7.1 x 6 inch
Notes
Source of data Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Röhren in FS-Bestückungstabellen
Mentioned in Radio-Mentor (4301)


All listed radios etc. from Tefag; Telephon Aktiengesellschaft vorm. J. Berliner
Here you find 254 models, 171 with images and 107 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
