Tefadyn 32W

Tefadyn 32W; Tefag; Telephon (ID = 47138) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47142) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47144) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47163) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47153) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47154) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47156) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47159) Radio

Tefadyn 32W; Tefag; Telephon (ID = 47147) Radio

Tefadyn 32W; Tefag; Telephon (ID = 14683) Radio
Tefadyn 32W; Tefag; Telephon (ID = 44406) Radio Tefadyn 32W; Tefag; Telephon (ID = 44407) Radio
Tefadyn 32W; Tefag; Telephon (ID = 1001866) Radio Tefadyn 32W; Tefag; Telephon (ID = 1001867) Radio
Tefadyn 32W; Tefag; Telephon (ID = 1001868) Radio Tefadyn 32W; Tefag; Telephon (ID = 1001870) Radio
Tefadyn 32W; Tefag; Telephon (ID = 1001871) Radio Tefadyn 32W; Tefag; Telephon (ID = 1001872) Radio
Use red slider bar for more.
Tefadyn 32W; Tefag; Telephon (ID = 44406) Radio
Tefag; Telephon: Tefadyn 32W [Radio] ID = 44406 933x698
Select picture or schematic to display from thumbnails on the right and click for download.
For model Tefadyn 32W, Tefag; Telephon Aktiengesellschaft vorm. J. Berliner

Country:  Germany
Manufacturer / Brand:  Tefag; Telephon Aktiengesellschaft vorm. J. Berliner
alternative name

Telephon-Fabrik, AG vorm. J. Berliner
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AF3 AF7 AL1 AZ1
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Tefadyn 32W - Tefag; Telephon
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 450 x 345 x 330 mm / 17.7 x 13.6 x 13 inch
Notes Ch=Konzertm.W
Price in first year of sale 230.00 RM
Collectors' prices
Source of data Katalog Radio-Zentrale Alex v. Prohaska 1935/1936 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung


All listed radios etc. from Tefag; Telephon Aktiengesellschaft vorm. J. Berliner
Here you find 254 models, 168 with images and 107 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.





rmXorg
