• Year
  • 1932/1933
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 4829
    • alternative name: Telephon-Fabrik, AG vorm. J. Berliner

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF with regeneration; 1 AF stage(s)
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Zielsicher I W - Tefag; Telephon
  • Dimensions (WHD)
  • 335 x 235 x 230 mm / 13.2 x 9.3 x 9.1 inch
  • Notes
  • Ch=München LW
  • Net weight (2.2 lb = 1 kg)
  • 4.3 kg / 9 lb 7.5 oz (9.471 lb)
  • Price in first year of sale
  • 118.00 RM !
  • Circuit diagram reference
  • Lange+Schenk+FS-Röhrenbestückung
