Herzog I W (1W)

Herzog I W ; TeKaDe TKD, (ID = 37698) Radio

Herzog I W ; TeKaDe TKD, (ID = 37699) Radio

Herzog I W ; TeKaDe TKD, (ID = 7179) Radio

Herzog I W ; TeKaDe TKD, (ID = 371107) Radio
Herzog I W ; TeKaDe TKD, (ID = 966087) Radio Herzog I W ; TeKaDe TKD, (ID = 966088) Radio
Use red slider bar for more.
Herzog I W ; TeKaDe TKD, (ID = 966087) Radio
TeKaDe TKD,: Herzog I W [Radio] ID = 966087 493x302
Select picture or schematic to display from thumbnails on the right and click for download.
For model Herzog I W (1W), TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg:
ebay 170617975649, schneeflocke133

Country:  Germany
Manufacturer / Brand:  TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg
alternative name

Felten & Guilleaume || Südd.Telefon-App., Kabel- und Drahtwerke AG || Telade
Brand
KD
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: AF3 AF7 AL1 AZ1
Main principle TRF with regeneration; 1 Special; 1 AF stage(s)
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Herzog I W - TeKaDe TKD, Süddeutsche
Price in first year of sale 243.00 RM
Source of data Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Mentioned in Radio Holzinger 1935/36


All listed radios etc. from TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg
Here you find 222 models, 189 with images and 92 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
