WK47; TeKaDe TKD, (ID = 7201) Radio

WK47; TeKaDe TKD, (ID = 809248) Radio
WK47; TeKaDe TKD, (ID = 657905) Radio WK47; TeKaDe TKD, (ID = 657907) Radio
WK47; TeKaDe TKD, (ID = 657906) Radio WK47; TeKaDe TKD, (ID = 657908) Radio
WK47; TeKaDe TKD, (ID = 809247) Radio
Use red slider bar for more.
WK47; TeKaDe TKD, (ID = 657905) Radio
TeKaDe TKD,: WK47 [Radio] ID = 657905 800x637
Select picture or schematic to display from thumbnails on the right and click for download.
For model WK47, TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg

Country:  Germany
Manufacturer / Brand:  TeKaDe (TKD), Süddeutsche Telefon-Apparate- Kabel- und Drahtwerke; Nürnberg
alternative name

Felten & Guilleaume || Südd.Telefon-App., Kabel- und Drahtwerke AG || Telade
Brand
KD
Year: 1947–1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: AF7 AL4 AZ1
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: WK47 - TeKaDe TKD, Süddeutsche
Material Wooden case
Dimensions (WHD) 410 x 280 x 180 mm / 16.1 x 11 x 7.1 inch
Notes KW=Reflex! [FS49-153]
Price in first year of sale 160.00 RM
Source of data Katalog Weide, 1949/50. / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange-Nowisch
Mentioned in Funk-Technik (FT) (4903)
