Oscilloscope 544

Oscilloscope 544; Tektronix Guernsey (ID = 2113159) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113160) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113161) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113162) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113163) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113164) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113165) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113166) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113167) Equipment

Oscilloscope 544; Tektronix Guernsey (ID = 2113168) Equipment
Oscilloscope 544; Tektronix Guernsey (ID = 2113157) Equipment Oscilloscope 544; Tektronix Guernsey (ID = 2113158) Equipment
Use red slider bar for more.
Oscilloscope 544; Tektronix Guernsey (ID = 2113157) Equipment
Tektronix Guernsey: Oscilloscope 544 [Equipment] ID = 2113157 1400x1582
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oscilloscope 544, Tektronix Guernsey Ltd. ; St.Peter Port:
544 shown here with U.S. made 1A5 plug-in

Country:  Guernsey
Manufacturer / Brand:  Tektronix Guernsey Ltd. ; St.Peter Port
Year: 1964–1972 ? Category: Service- or Lab Equipment
Valves / Tubes 33: 5642 6080 6197 6AU5 6AU6 6BY8 6CW5 6DJ8 12AT7 12AU6 12AU7 12AX7 0G3
Semiconductors (the count is only for transistors) 27:
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 100; 115; 124; 200; 230; 248 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oscilloscope 544 - Tektronix Guernsey Ltd. ; St.
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 329 x 432 x 607 mm / 13 x 17 x 23.9 inch
Notes

This page is for the Guernsey made Tektronix 544. The same instrument was produced in USA by Tektronix INC. Beaverton. Although the specs are the same, the internals differ slightly. See http://w140.com/tekwiki/wiki/544 for diagrams and parts list for the Beaverton version.

Diagrams and parts lists for the Guernsey 544 are not generally available. Owners can now access them here.



Net weight (2.2 lb = 1 kg) 27.8 kg / 61 lb 3.7 oz (61.233 lb)
Mentioned in - - Manufacturers Literature

Model page created by Erik Thomsen. See "Data change" for further contributors.
